Green German Rehau Profile PVC Windows and Doors with Ass2208 Glazed Certification
Product Details:
| Place of Origin: | Shanghai, China |
| Brand Name: | minye |
| Model Number: | MY0501002208 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 square meters |
|---|---|
| Price: | $85.00 - $240.00/square meters |
| Packaging Details: | PVC&UPVC window <br>1).Plastic film+plastic belts+airbags <br>2).Protective tape+wooden pallets and strips <br>3).Iron pallet + Air bubble film+ Plastic film |
| Supply Ability: | 6000 Square Meter/Square Meters per Month PVC&UPVC window |
|
Detail Information |
|||
| Frame Material: | Aluminum Alloy | Opening Pattern: | Horizontal |
|---|---|---|---|
| Open Style: | Swing | Products: | PVC&UPVC Window |
| Color: | Grey ,brown,green ,coffee ,customized | Profile: | Aluminum Alloy |
| Wind Resistance: | 3500 Pa | Water Penetration: | 300 Pa |
| Sound Proof: | 30 -40DB | Port: | Shanghai |
Product Description
LUXURY DESIGN UPVC/PVC WINDOW
1) Long life span (10-30 years), Noise insulation, various colors for choice.
2) Durable, no deformation, no crack after long-time usage.
3) Security, can be closed and locked firmly.
4) Easy to install, with very nice appearance.
5) Fit for different rooms, with wide field of vision.
6) Surface treatment: Powder Coating, Fluorocarbon Coating, ect.
7) Accessory system: High quality accessories achieved American and European standard.
PRODUCT DESCRIPTION
| Doors Description | Glass sliding doors,Aluminum sliding door | |||||
| Profile | 1.CE 6063-T5/T6thermal break aluminum profile(heat insulation) | |||||
| 2.CE 6063-T5/T6 standard aluminum profile | ||||||
| 3.UPVC/PVC profile(Conch,LG,Koemmerling,VEKA Brand) | ||||||
| 4.aluminum cladding wood profile | ||||||
| Glass | 1.Single toughened(tempered) glass 4mm.5mm.6mm.8mm.12mm | |||||
| 2.Double Glazed:5+9A+5mm,5+12A+5mm,6+19A+6mm | ||||||
| 3.Laminated glass:5+0.38PVB+5mm,5+0.76PVB+5mm | ||||||
| 4.Tinted lowe glass,Obsucre glass,reflection glass Self-cleaning glass,Art glass | ||||||
| Hardware | 1.China Brand:KIN LONG,YAHR, CHUGN | |||||
| 2.German Brand:ROTO,SIEGENIA,HOPPE | ||||||
| 3.Italy Brand:ALUK,SAVIO,GIESSE | ||||||
| Profile finished | Aluminum:powder coating,Anodized, Electrophoresis,Wood grain | |||||
| UPVC/PVC:Coextrusion,laminating,embossed | ||||||
| Sealing | PVC & EPDM rubber strip,silicone sealant, wool piled pipe | |||||
REHAU PVC&UPVC WINDOW
Glass Details
(Laminated glass for skylight)
1) Insulated glass is made of two or more pieces of glass sheets and use sealant gumming glass piece and aluminum spacers which was filled with desiccant together.Insulated glass with the perimeter of the spacer that gets in contact with the glass is properly sealed with primary and secondary sealants to ensure its air tight. Due to its perfect sound insulation and energy saving performance, the modern most popular used glass would be blow hollow glass.
2) Insulated glass performance characteristics:
l.Thermal insulation: with low heat gain and heat loss value (low U value)
2. Light transmission: appropriate level of solar transmission and solar reflectance can be selected to meet the design and functional requirement.
Laminated glass
3. Noise insulation: insulated glass/hollow glass/double glazing glass, can reduce noise level by 30 dB. With inert gas in-filled, a 5 dB further reduction can be achieved.
4. Condensing prevention: The insulated glass/hollow glass/double glazing glass units are designed to withstand down to -65°C without condensing, far exceeding the National Requirement of -40°C.
5. Leak-proof: to ensure the insulated glass/hollow glass/double glazing glass, air tight, automatic bending machine is used for all four corners bending, with use of linear connector for the spacer. A dual seal system is adopted with PIB as primary seal, and silicone or polysulfide as secondary seal.
(Double glass with Low-E for skylight)
window style for you choose
automatic skylight hardware
| Excellent Performance | |
| 1:sound insulation : | RW>30DB |
| 2:wind pressure Resistance: | Third clsss(GB/106) |
| 3:Air Permeation Resistance: | Third class(GB/108) |
| 4:Heat insulation Resistance: | Third:2.8/(m2k),2.5W/(m2k),or below2.0w/(m2k) |
| 5:water penetration | 350 PA |
Double Insulation Glass
The colors of profiles for you choose.
Our Company Certifications
The Packing
Adopt international standard packing, not easily to be damaged, convenient
for remounted and carried .
1).Plastic film+plastic belts+airbags
2).Protective tape+wooden pallets and strips
3).Iron pallet + Air bubble film+ Plastic film
4) All those methods to make goods arrived at your side in good condition,
Contact us for details if you have own of packages pls .
THE REASON YOU CHOOSE US
1. | the payment is flexible , we accept T/T , L/C ,Western Union . |
| 2. | the delivery time: as usual , 30 days after comfirming the order , if the quantity is big and urgent 2 months (15 x 40HQ we can do) |
| 3. | Capacity : workers are skilled and have strict QC to control the quality . there are 3 engineers ( they have more than 10 years experienceS in this area ) |
| 4. | Service : when we get your inqury .we will reply you in intraday and hv no delay the time . Also we will quote to you our reasonable price according to your requirements .. |
| 5. | Packing : there is need wooden case to fasten the windows and doors , the packing is strong . supposed you get broken windows and make a survey ,if it is our packing problem we will make compensation . |
| 6. | Samples : if you need samples , we can offer it. And also if you want to widen your local market to show the quality , pls contact us . We will definitely meet your request !! |
Company Project Programes
